- 3 inch competition Voice Coil
- SPL competition performance
- High Power handling
BD15SPL-V2: BlackDeath 15 Inch Street Bass Subwoofer
Need help fitting?
This product requires specific tools to fit, we recommend having this product installed by a professionalFind a dealer
The new BlackDeath 15 Inch Street Bass subwoofer takes a huge 300oz triple stack magnet with Paper Kevlar composite cone for monstrous bass and insane levels of SPL.
The BlackDeath Subwoofer series has always been one of VIBE’s most popular product ranges. Capable of 4500w peak, the BlackDeath 15 Inch Street Bass Subwoofer is the BlackDeath subwoofer VIBE fans have been demanding for years.
BlackDeath 15 Inch Street Bass Subwoofer has a die cast alloy basket provides support for the huge motor system and a non pressed paper cone with woven Kevlar fibres. NT multi-layer foam surround with double stitching along with Black Hole dust-cap, increases effective cone area and SPL. Alloy angular torsion chassis supports the moving parts of the woofer. Triple stack 300oz magnet array provides massive moving force for the motor system. FEMM (Finite Method Method Magnetics) designed motor system ensures linear flux saturation and minimal distortion. Vented linear motor design. 10AWG speaker cable attached directly to tinsel leads. 3” high temperature aluminium long wound dual 2Ω voice coil. Heavy current Tinsel leads woven into spider.
- Model BD15SPL-V2
- Configuration Component subwoofer
- Speaker size 15” (392mm)
- RMS power 1500 watts
- Peak power 4500 watts
- Minimum input (RMS) 750 watts RMS
- Sensitivity 88dB
- Frequency response 20Hz – 850Hz
- Voice coil 3” long wound Dual 2Ω
- Mounting depth 8.3” (210mm)
- Mounting diameter 13.8” (350mm)
- Magnet rating Y30
Click download below to view PDF versions of the manuals for this product
Need more help?
Get in touch
|Dimensions||46 × 46 × 32 cm|
